DC-DV SERIES

Cooling capacity 60/950 kW

The DC-DV Series

The DC-DV series has been designed using modules of different sizes and suitable fans to obtain the maximum cooling capacity possible with the least footprint on the ground.

The heat exchange batteries are V-shaped with internal partition.

Frame

In its standard version, each unit is made with a pre-painted galvanized steel frame. On request, depending on the installation site, various surface treatments are available aimed at preserving the life of the cooler.

Heat exchange batteries

They are made with geometries suitable for the most diverse applications and temperatures, with ½” and 5/8″ tube and aluminum fins.

The two batteries are V-shaped inside the frame and divided by a partition that allows the independent use of the two rows of fans (V2 series). Each battery is tested with pressures up to 18 Bar, to ensure proper tightness.

Fans

The units are equipped with AC fans (standard phase cut) with diameters from 800 to 910 mm. EC fans can be mounted on request.

Control

Microprocessor control panel mounted on board, also available in remote version (option).

Standard supply

• Fans speed control

• Alarm relay

• Remote ON/OFF
